Edge EXT SQ FLOOR (R)

Architectural floor recessed square uplight for exterior applications

Product Overview

✔ Architectural floor accent light for enhancing exterior spaces

✔ Individually lensed LEDs for ultimate optical control

✔ Ultra transparent tempered glass diffuser ensures maximum light transmittance

✔ Silicone gaskets ensure maximum sealing and full operation in all weather conditions

✔ Supplied with water-lock system stopping humidity from impacting performance

✔ Constructed of high oxidation resistant aluminum alloy

✔ Durable Stainless Steel bezel and fixings for longevity

✔ UV Resistant

✔ Suitable for Monuments & statues, Walkways, Driveways, Canopies / Entrance Areas

Finishes / Material
  • Stainless Steel
  • Bezel: Steel
    Stainless Steel
  • Body: Extruded Aluminium
    High oxidation resistant aluminum alloy
  • Diffuser: Tempered glass
Sizes
  • 120 (L) x 120 (W) x 85 (D) mm
    Cutout: 123 x 123 mm
  • Source Info Tier 1 LED components (Tridonic, Philips, Osram)
  • Lumens (delivered) 890Lm, 1237Lm, 1669Lm
  • Circuit Watts 11cW, 16cW, 22cW
  • Efficacy up to 80Lm/cW
  • MacAdams 3 SDCM
  • Colour Temperature 3000K / 4000K
  • Colour Rendering CRI90

Options.

Beam Angle

  • 17° Beam Angle
  • 37° Beam Angle
  • 50° Beam Angle
  • Asymmetrical Distribution

    19x32°

Additional Information.

Series of ground recessed lighting fixtures. Available in various sizes, they are designed for the lighting of facades, small, medium and tall trees, shrubs, columns and other architectural elements thanks to a wide range of optics and powers. The construction of the aluminium alloy body with high oxidation resistance subjected to treatment with nano-bonderite protected with textured polyester powder coating, make the product resistant to atmospheric agents and UV rays, guaranteeing maximum protection over the years. The silicone gaskets ensure maximum sealing in all operating conditions and temperatures. The hyper-transparent tempered sodium-calcium glass diffuser, to ensure maximum light transmittance, is finished with a silk-screened edge. The product is equipped with the special Ghidini water-lock system which prevents the suction of humidity from the power cable caused by alternating on and off cycles. The product is installed with a form-work that allows to have the necessary space for wiring. The product can be walked on. Not suitable for installation in swimming pools or fountains.
