Ribbon Horizontal Bend (RGBW)

Horizontal bend IP rated, miniature flexible tape light, 4 colours in one LED

Product Overview

✔ RGBW, Four chips in each LED, for RGB + your choice of High CRI White

✔ Miniature solution, ideal for direct lighting (i.e. bends and curves)

✔ Constant Current for long length applications up to 20m

✔ Homogeneous light distribution

✔ Resistant to salt water & solvents

✔ Injection moulded end caps

✔ UV Protection

✔ LM80 Standard

✔ IP67 as standard

✔ Fixing and mounting profiles available

✔ Suitable for Hospitality, Retail, Commercial, Gallery/Museum, Residential, Parks & Gardens

Material
  • Body: Silicone
Sizes
  • (L) XM
    12mm width
  • (L) XM
    16mm width

*Please Note: Made to measure lengths - Contact sales to order

Technical Drawing
  • Source Info Tier 1 LED
  • Cut points 62.5mm, 125mm
  • Lumens (delivered per metre) 185Lm - 450Lm
  • Watts (per Metre) 5W - 15W
  • Efficacy up to 37Lm/cW
  • MacAdams 3 SDCM
  • Colour Temperature 2700K (Plus RGB in one chip) / 3000K (Plus RGB in one chip) / 4000K (Plus RGB in one chip) / 6000K (Plus RGB in one chip)
  • Colour Rendering CRI90

Options.

Cable Entry

  • Cable entry: Front

    Injection moulded end caps

  • Cable entry: Bottom

    Injection moulded end caps

  • Cable entry: Side

    Injection moulded end caps

Cable Length

  • Power cable length (0.3m)

    Standard

  • Power cable length (2m)

    Cut on site

Additional Information.

Ribbon HB RGBW is a colour changing flexible tape light with choice of white light. Ribbon is a type of side view bendy, waterproof flexible LED tape light which is far more flexible that traditional LED strip lighting. Ribbon HB is a silicone IP67 rated LED tape light which bends horizontally. This waterproof tape light can be used on buildings outdoors for high quality architectural outdoor feature lighting. Ribbon is a tape light with injection moulded end caps.

Need Assistance? If you need help finding the perfect light for your project we can help. From product selection, price enquiry & technical support, we’ll be happy to assist. Please make contact via our contact page.
